Product Details
BrandVICTOR
Manufacturer Part Number0781-0527
Regulator SeriesSR 450
For Gas TypeOxygen
Mounting TypeCylinder
Number of StagesSingle Stage
CGA NumberCGA 540
Inlet ConnectionCGA 540
Inlet Connection TypeNGO
Inlet Connection GenderMale
Inlet Connection Size0.825"-14
Inlet Thread DirectionRight Hand
Inlet Pressure (Maximum)3,000 psig
Outlet Connection9/16"-18 M RH
Outlet Connection TypeUNF
Outlet Connection GenderMale
Outlet Connection Size9/16"-18
Outlet Thread DirectionRight Hand
Outlet Pressure (Maximum)125 psig
Outlet Pressure (Minimum)5 psig
Body MaterialBrass
Diaphragm MaterialStainless Steel
Control TypeT-Handle
Flow Coefficient0.27
Maximum Gauge Outlet Pressure4,000 psig
Body Diameter3.5 in
Gauge Diameter2-1/2 in
Overall Depth5.13 in
Overall Height7 in
Overall Width7.25 in
ApplicationCutting; Heating; Welding
FeaturesTried and True Brass Design Delivers Excellent Gas Control Characteristics That Meets the Demands of Precise Cutting, Welding and Heating Applications
StandardsETL Listed; UL252
UNSPSC40142201
Country of OriginMexico (subject to change)
